| PartNumber | P101DCZ-3Z0 |
| Brand | Innolux |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 800×1280 |
| Composition | CELL , a-Si TFT-LC |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | MIPI |
| Manufacturer | Innolux |
| Screen Size | 10.1 inch |
| Pixel Number | 800(RGB)×1280 (WXGA) 150PPI |
| Active Area(mm) | 135.36 × 216.576 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 0 cd/m² |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Glass Thickness | - |
| Color Depth | 16.7M 59% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Signal Type | MIPI (4 data lanes) , 40 pins Connector |
| Voltage Supply | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | P101DCZ-3Z0 |
| Screen Type | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | - |
| Treatment | Clear, Hard coating (3H) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | AAS, Normally Black, Transmissive |
| Transmissivity | 4.73% (Typ.)(with Polarizer) |
| Used for | Pad & Tablet |
| Touchscreen | Without |
