| PartNumber | PD035VX2 |
| Brand | E Ink |
| Size | 3.5 |
| Application | PND |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | PVI |
| Panel Model | PD035VX2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 72×52.56 mm |
| Outline | 84.03×65.24 mm |
| Surface | Antiglare |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3S2PWLEDWithout Driver |
| Signal Interface | TTL (1 ch, 6-bit), 50 pins |
| Input Voltage | 3.3/3.3/10/17/-10V (Typ.)(VCC/VDD/VDD1/VCG/VEE) |
