| PartNumber | PD121XL3 |
| Brand | E Ink |
| Size | 12.1 |
| Application | IA |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 1700 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | PVI |
| Panel Model | PD121XL3 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 12.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 245.76×184.32 mm |
| Outline | 263.5×204×26.3 mm |
| Surface | Antiglare, Hard coating |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 10/20 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 14S4PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
