| PartNumber | PDP42X |
| Brand | LG Display |
| Size | 42 |
| Application | TV Sets Digital Signage |
| Resolution | 1024(RGB)×768, XGA, 30PPI |
| Composition | PDP, PDP |
| Brightness | 1200 cd/m² (Typ.) |
| CR | - |
| Colors | 1.07B |
| Backlight | self |
| Interface | LVDS |
| Panel Brand | LG Display |
| Panel Model | PDP42X |
| Panel Size | 42" |
| Panel Type | PDP, PDP |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 920.1(W)×518.4(H) mm |
| Bezel Opening | - |
| Outline Size | 1005(W)×597(H) ×60.7(D) mm |
| Surface | - |
| Contrast Ratio | - |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | - |
| Response Time | - |
| Display Colors | 1.07B |
| Lamp Type | self , 100K hours |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 14.7±0.5Kgs |
| Signal Interface | LVDS (1 ch, 10-bit) , 31 pins Connector |
| Environment | Operating Temp.: 0 ~ 40 °C ; Storage Temp.: -20 ~ 60 °C |
