| PartNumber | PT320CT01-1 |
| Brand | HKC |
| Size | 32.0 |
| Application | TV Sets |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | LVDS |
| Model | PT320CT01-1 |
| Diagonal Size | 32.0 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1920×1080(RGB) [FHD] 69PPI |
| Configuration | RGB Horizontal Stripe |
| Active Area | 698.4(H)×392.85(V) mm |
| Outline Dim. | 715(H)×411(V) ×1.39(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 3%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 8.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | FSA, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 5.5% (Typ.)(with Polarizer) |
| Support Color | 16.7M 69% NTSC |
| Light Source | No B/L |
| Weight | 924g (Typ.) |
| Designed For | TV Sets |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COF Built-in 2 source chips |
| Interface Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
