| PartNumber | PT430CT01-1 |
| Brand | HKC |
| Size | 43 |
| Application | TV Sets |
| Resolution | 1920×1080 |
| Composition | CELL , a-Si TFT-LC |
| Brightness | |
| CR | 4000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Manufacturer | HKC |
| Model Name | PT430CT01-1 |
| Screen Size | 43 inch |
| Screen Type | CELL , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 51PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 940.896 × 529.254 (H×V) |
| Outline(mm) | 953 × 543 × 1.37 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare (Haze 3%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 4000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 9.5 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | FSA, Normally Black, Transmissive |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | 7.0% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 68% NTSC |
| Mass | 1.60Kgs (Typ.) |
| Used for | TV Sets |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Driver IC list | Built-in COF 6 source + 3 gate chips |
| Signal Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
