| PartNumber | PT430GT01-2 |
| Brand | HKC |
| Size | 43 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 103PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | USI-T |
| Panel Brand | HKC |
| Panel Model | PT430GT01-2 |
| Panel Size | 43" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 941.184(W)×529.416(H) mm |
| Bezel Opening | - |
| Outline Size | 953(W)×543(H) ×1.43(D) mm |
| Surface | Hard coating (3H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | FSA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 9.5 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | - |
| Display Colors | 1.07B |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COFBuilt-in 12 source chips |
| Panel Weight | - |
| Signal Interface | USI-T Connector |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HV430FHB-N4A | BOE | 43 | 1920×1080 |
| LC430DUY-SHA1 | LG Display | 43 | 1920×1080 |
| LC430EGG-FHM1 | LG Display | 43 | 3840×2160 |
| LC430EQL-SHA2 | LG Display | 43 | 3840×2160 |
| LC430EUE-FHM1 | LG Display | 43 | 1920×1080 |
| LC430EUE-FHM2 | LG Display | 43 | 1920×1080 |
| LTA430HW01 | Samsung | 43 | 1920×1080 |
| LTI430LA01 | Samsung | 43 | 1920×480 |
| RX430HD02-DC15 | ROGIN | 43 | 1920×1080 |
| T430QVN01.0 CELL | AUO | 43 | 3840×2160 |
