| PartNumber | PT500GT02-9 |
| Brand | HKC |
| Size | 50 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 89PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | HKC |
| Panel Model | PT500GT02-9 |
| Panel Size | 50" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1095.84(W)×616.41(H) mm |
| Bezel Opening | - |
| Outline Size | 1106.84(W)×618.81(H) ×1.37(D) mm |
| Surface | Antiglare (Haze 3%), Hard coating (3H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | FSA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 9.5 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 5.0% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COFBuilt-in 12 source chips |
| Panel Weight | 2.15Kgs (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC500EUE-FFF1 | LG Display | 50 | 1920×1080 |
| T500HVN02.2 CELL | AUO | 50 | 1920×1080 |
| V500DJ2-KS5 | Innolux | 50 | 3840×2160 |
| V500DK1-KS1 | Innolux | 50 | 3840×2160 |
| V500DK1-KS2 Rev.HA | Innolux | 50 | 3840×2160 |
| V500DK1-LS1 | Innolux | 50 | 3840×2160 |
| V500HJ1-LE1 | Innolux | 50 | 1920×1080 |
| V500HJ1-LE8 | Innolux | 50 | 1920×1080 |
| V500HK1-LE1 | Innolux | 50 | 1920×1080 |
| V500HK1-LE6 | Innolux | 50 | 1920×1080 |
