| PartNumber | PW062XU8 |
| Brand | E Ink |
| Size | 6.2 |
| Application | CNS |
| Resolution | 480(RGB)×234 |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | Full color |
| Backlight | WLED |
| Interface | Analog |
| Panel Brand | PVI |
| Panel Model | PW062XU8 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.2 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 137.52×77.22 mm |
| Outline | 155.2×88.2 mm |
| Surface | Antiglare |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3S8PWLEDWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 26 pins |
| Input Voltage | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ049B5DG02 | SHARP | 4.9 | 320×96 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| NL4827HC19-05A | NLT | 4.3 | 480×272 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
