| PartNumber | QT070WVM-NH0 |
| Brand | BOE |
| Size | 7.0 |
| Application | Home Appliance |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 7.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 134PPI |
| Active Area | 153.84(H)×85.632(V) mm |
| Bezel Area | - |
| Luminance | 350 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Support Color | 16.7M 50% NTSC |
| Weight | 160g (Typ.) |
| Frame Rate | 60Hz |
| Model | QT070WVM-NH0 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 164.9(H)×100(V) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , W/O Driver |
| Designed For | Home Appliance |
| Touch Panel | Without |
