| PartNumber | QV116FHB-N81 |
| Brand | BOE |
| Size | 11.6 |
| Application | Industrial |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | eDP |
| Model | QV116FHB-N81 |
| Diagonal Size | 11.6 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 190PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 256.32(H)×144.18(V) mm |
| Outline Dim. | 260.32(H)×152.08(V) ×1.06(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | - |
| Support Color | 16.7M |
| Light Source | No B/L |
| Weight | TBD |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COG Built-in 4 source chips |
| Interface Type | eDP (2 Lanes) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
