R133NWF4 R9


Brand
IVO
Size
13.3
Application
Laptop
Resolution
1920×1080
Composition
a-Si TFT-LCD, LCM
Brightness
CR
600:1
Colors
262K
Backlight
WLED
Interface
In Stock
12738
Specifications
PartNumber R133NWF4 R9
BrandIVO
Size13.3
ApplicationLaptop
Resolution1920×1080
Compositiona-Si TFT-LCD, LCM
Brightness
CR600:1
Colors262K
BacklightWLED
Interface
ModelR133NWF4 R9 (IVO0536)
Diagonal Size13.3 inch
Typea-Si TFT-LCD, LCM
Pixel Format1920(RGB)×1080  [FHD]  166PPI
ConfigurationRGB Vertical Stripe
Active Area293.76(H)×165.24(V) mm
Outline Dim.305.35(H)×195.04(V) ×3.2(D) mm
Bezel Area-
TreatmentGlare (Haze 0%), Hard coating (3H)
Luminance220 cd/m² (Typ.)
Contrast Ratio600:1 (Typ.) (TM)
View DirectionSymmetry
Response Time25 (Typ.)(Tr+Td)
Viewing Angle85/85/85/85 (Typ.)(CR≥10)
Operating ModeIPS, Normally Black, Transmissive
Support Color262K   48% NTSC
Light SourceWLED , 15K hours , With LED Driver
Form StyleSlim (PCBA Flat, T≤3.2mm)
Designed ForLaptop
Frame Rate60Hz
Touch PanelOn-Cell Touch
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
