| PartNumber | R156B48-167-0101 |
| Brand | No Brand |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 1366(RGB)×768, WXGA, 100PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 8S6P |
| Interface | LVDS |
| Panel Brand | No Brand |
| Panel Model | R156B48-167-0101 1 Compatible |
| Panel Size | 15.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.232(W)×193.536(H) mm |
| Bezel Opening | - |
| Outline Size | 359.3(W)×209.5(H) ×5.5(D) mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 12 (Typ.)(Tr+Td) |
| Display Colors | 262K 45% NTSC |
| Lamp Type | 8S6P WLED , 15K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | Wedge (PCBA Bent, T≥5.2mm) |
| Signal Interface | LVDS (1 ch, 6-bit) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
