| PartNumber | S035V04-T |
| Brand | CDTECH |
| Size | 3.5 |
| Application | Industrial Handheld & PDA |
| Resolution | 480(RGB)×640, VGA, 228PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 650 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 8S1P |
| Interface | Parallel |
| Panel Brand | CDTECH |
| Panel Model | S035V04-T |
| Panel Size | 3.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 53.28(W)×71.04(H) mm |
| Bezel Opening | - |
| Outline Size | 64(W)×85(H) ×5(D) mm |
| Surface | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 65/65/55/65 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 9 o'clock |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 262K 50% NTSC |
| Lamp Type | 8S1P WLED , 25K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | 4-wire Resistive Touch |
| Panel Weight | TBD |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 39 pins FPC |
| Input Voltage | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
