| PartNumber | S039WQ01 |
| Brand | CDTECH |
| Size | 3.9 |
| Application | Industrial Stretched |
| Resolution | 480×128 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 5S2P WLED , 30K hours , No Driver |
| Interface | |
| Manufacturer | CDTECH |
| Model Name | S039WQ01 |
| Screen Size | 3.9 inch (1/2 cut of 4.3") |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 480(RGB)×128 128PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 95.04 × 25.34 (H×V) |
| Outline(mm) | 105.5 × 40.64 × 3.15 (H×V×D) |
| Bezel Area(mm) | 98.04 × 28.34 (H×V) |
| Treatment | - |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/55/65 (Typ.)(CR≥10) |
| Response | 10/15 (Typ.)(Tr/Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Mass | TBD |
| Used for | Industrial Stretched Bar LCD Automotive Display |
| Refresh Rate | - |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
