| PartNumber | S065WV03 |
| Brand | CDTECH |
| Size | 6.5 |
| Application | Industrial Stretched Bar LCD |
| Resolution | 800(RGB)×320, 133PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 3S7P |
| Interface | |
| Panel Brand | CDTECH |
| Panel Size | 6.5" (2/3 cut of 7.0") |
| Display Area | 154.08(W)×57.28(H) mm |
| Outline Size | 165(W)×72.86(H) mm |
| Viewing Angle | 65/65/55/65 (Typ.)(CR≥10) |
| Best View on | 12 o'clock |
| Display Colors | 16.7M 55% NTSC |
| Frequency | 60Hz |
| Weight | TBD |
| Panel Model | S065WV03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 156.7(W)×60.66(H) mm |
| Surface | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Lamp Type | 3S7P WLED , 30K hours , Without Driver |
| Touch Screen | Without |
