| PartNumber | S50HW-YB06 |
| Brand | Samsung |
| Size | 50 |
| Application | LCTV |
| Resolution | 1365(RGB)×768 , WXGA |
| Composition | PDP |
| Brightness | 630 cd/m² (Typ.) |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | self |
| Interface | LVDS |
| Panel Brand | SAMSUNG SDI |
| Panel Model | S50HW-YB06 |
| Panel Type | PDP , PDP |
| Panel Size | 50 inch |
| Active Area | 1105.65×622.08 mm |
| Outline | 1175.4×688 mm |
| Surface | |
| Contrast Ratio | 5000 : 1 (Typ.) |
| Display Colors | 1.07B (10-bit) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 10-bit) + SPI, 30 pins |
