SG2151B05-2


Brand
CSOT
Size
21.5
Application
Desktop Monitor Digi
Resolution
1920×1080
Composition
a-Si TFT-LCD , CELL
Brightness
CR
3000:1
Colors
16.7M
Backlight
No
Interface
In Stock
15974
Specifications
PartNumber SG2151B05-2
BrandCSOT
Size21.5
ApplicationDesktop Monitor Digital Signage
Resolution1920(RGB)×1080, FHD, 102PPI
Compositiona-Si TFT-LCD , CELL
Brightness0 cd/m²
CR3000:1
Colors16.7M
BacklightNo
Interface
Panel BrandCSOT
Panel Size21.5"
Display Area478.656(W)×260.28(H) mm
Outline Size487.456(W)×270.18(H) ×1.34(D) mm
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Best View onSymmetry
Glass Depth0.50+0.50 mm
Display Colors16.7M   72% NTSC
Frequency60Hz
Weight400g (Typ.)
Panel ModelSG2151B05-2
Panel Typea-Si TFT-LCD , CELL
Pixel FormatRGB Vertical Stripe
Bezel Opening-
SurfaceAntiglare (Haze 25%), Hard coating (3H)
Contrast Ratio3000:1 (Typ.) (TM)
Display ModeVA, Normally Black, Transmissive
Response Time6.5 (Typ.)(G to G)
Transmissivity4.9% (Typ.)(with Polarizer)
Lamp TypeNo B/L
Touch ScreenWithout
