PartNumber | SG215FHB-A30 |
Brand | BOE |
Size | 21.5 |
Application | Desktop Monitor |
Resolution | 1920×1080 |
Composition | CELL , a-Si TFT-LC |
Brightness | |
CR | 1000:1 |
Colors | 16.7M |
Backlight | No B/L |
Interface | |
Manufacturer | BOE |
Model Name | SG215FHB-A30 |
Screen Size | 21.5 inch |
Screen Type | CELL , a-Si TFT-LCD |
Pixel Number | 1920(RGB)×1080 (FHD) 102PPI |
Arrangement | RGB Vertical Stripe |
Active Area(mm) | 476.64 × 268.11 (H×V) |
Outline(mm) | - |
Luminance | 0 cd/m² |
Contrast Ratio | 1000 : 1 (Typ.) (TM) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Response | 14 (Typ.)(G to G) ms |
Good View at | Symmetry |
Work Mode | AFFS, Normally Black, Transmissive |
Glass Thickness | 0.50+0.50 mm |
Transmissivity | - |
Color Depth | 16.7M |
Mass | - |
Used for | Desktop Monitor |
Refresh Rate | 60Hz |
Touchscreen | PCAP |
Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
