| PartNumber | SG8561D01-1 |
| Brand | CSOT |
| Size | 86 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 51PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 4000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | V-by-One |
| Panel Brand | CSOT |
| Panel Size | 86" |
| Display Area | 1895.04(W)×1065.96(H) mm |
| Outline Size | 1913.04(W)×1083.96(H) ×1.34(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.50+0.50 mm |
| Display Colors | 1.07B 75% DCI-P3 |
| Frequency | 60Hz |
| Driver IC | COF Built-in 16 source + 16 gate chips |
| Panel Weight | 6.50Kgs (Typ.) |
| Signal Interface | V-by-One 8 lane , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | SG8561D01-1 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 4000:1 (Typ.) (TM) |
| Display Mode | HVA, Normally Black, Transmissive |
| Response Time | 6.5 (Typ.)(G to G) |
| Transmissivity | 5.5% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
