| PartNumber | SH320240C |
| Brand | Other |
| Size | 5.7 |
| Application | IA |
| Resolution | 320×240 , QVGA |
| Composition | LCM |
| Brightness | |
| CR | |
| Colors | Monochrome |
| Backlight | WLED |
| Interface | CPU |
| Panel Brand | Amson |
| Panel Model | SH320240C |
| Panel Type | FSTN-LCD , LCM |
| Panel Size | 5.7 inch |
| Display Mode | STN, Black/White (Positive), Transflective |
| Active Area | 115.17×86.37 mm |
| Outline | 148×120.2×20.5 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | Monochrome |
| Response Time | |
| Viewing Angle | |
| Lamp Type | WLEDWithout Driver |
| Signal Interface | 8-bit parallel, 20 pins |
| Input Voltage | 5.0V (Typ.) |
