| PartNumber | SP10Q010 |
| Brand | KOE |
| Size | 3.8 |
| Application | IA |
| Resolution | 320×240 , QVGA |
| Composition | LCM |
| Brightness | 110 cd/m² (Typ.) |
| CR | 20:1 |
| Colors | Monochrome |
| Backlight | WLED |
| Interface | Parallel Data |
| Panel Brand | KOE |
| Panel Model | SP10Q010 |
| Panel Type | FSTN-LCD , LCM |
| Panel Size | 3.8 inch |
| Display Mode | STN, Black/White (Negative), Transmissive |
| Active Area | 76.79×57.59 mm |
| Outline | 94.7×73.3×6 mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 20:1 (Typ.) |
| Display Colors | Monochrome |
| Response Time | 150/350 (Typ.)(Tr/Td) |
| Viewing Angle | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| Frequency | 75Hz |
| Lamp Type | 1S6PWLEDWithout Driver |
| Signal Interface | Parallel Data (4-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
