| PartNumber | ST5461B03-1 |
| Brand | CSOT |
| Size | 55 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 4000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | CSOT |
| Panel Model | ST5461B03-1 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 55 inch |
| Display Mode | HVA, Normally Black, Transmissive |
| Active Area | 1209.6×680.4 mm |
| Outline | 1223.6×697.1 mm |
| Surface | Antiglare (Haze 2%), Hard coating (3H) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 6.5% (Typ.)(with Polarizer) |
| Contrast Ratio | 4000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 6.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Voltage | 12.0V (Typ.) |
| LD550DUN-TGB1 | LG Display | 55 | 1920×1080 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-2 | CSOT | 55 | 1920×1080 |
| ST5461D01-1 | CSOT | 55 | 3840×2160 |
| ST5461D04-2 | CSOT | 55 | 3840×2160 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| T546HW04 V3 | AUO | 55 | 1920×1080 |
| V546H1-LH2 | Innolux | 55 | 1920×1080 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| LC320EUN-FFM1 | LG Display | 31.5 | 1920×1080 |
| LC420EUD-SEF2 | LG Display | 42 | 1920×1080 |
| LC420EUN-FFM1 | LG Display | 42 | 1920×1080 |
| LC470EUE-SEM1 | LG Display | 47 | 1920×1080 |
| LC550WUD-SBM3 | LG Display | 55 | 1920×1080 |
| LK600D3LA3K | SHARP | 60 | 1920×1080 |
| LTY520HE06 | Samsung | 52 | 1920×1080 |
| T460HW08 VC | AUO | 46 | 1920×1080 |
| V260H1-LE2 | Innolux | 26.0 | 1920×1080 |
| V470H1-L03 | Innolux | 47 | 1920×1080 |
