| PartNumber | SVGA038SCV1R1 |
| Brand | OLiGHTEK |
| Size | 0.38 |
| Application | HMD VR AR |
| Resolution | 800×600 |
| Composition | Si-OLED, OLED |
| Brightness | |
| CR | 10000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | Parallel |
| Model | SVGA038SCV1R1 |
| Diagonal Size | 0.38 inch |
| Type | Si-OLED, OLED |
| Pixel Format | 800(RGB)×600 [SVGA] 2631PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 7.718(H)×5.798(V) mm |
| Outline Dim. | 15(H)×19(V) mm |
| Bezel Area | 7.718(H)×5.798(V) mm |
| Treatment | - |
| Luminance | 70 cd/m² (Typ.) |
| Contrast Ratio | 10000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | - |
| Support Color | 16.7M |
| Light Source | self |
| Weight | 2.00g (Max.) |
| Designed For | HMD VR AR |
| Frame Rate | 85Hz |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 8-bit), CCIR601/656 , 40 pins Connector |
| Power Supply | 1.8/5.0V (Typ.) |
| Environment | Operating Temperature: -40 ~ 65 °C ; Storage Temperature: -55 ~ 90 °C |
