| PartNumber | T-51965GD088ZU-MFW-A-AJN |
| Brand | OPTREX |
| Size | 8.8 |
| Application | Automotive Display |
| Resolution | 640×240 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 185:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | CMOS |
| Model | T-51965GD088ZU-MFW-A-AJN 1 Compatible |
| Diagonal Size | 8.8 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 640(RGB)×240 [HVGA] 77PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 209.28(H)×78.48(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 185:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | TN, Normally White, Transflective |
| Support Color | 262K |
| Light Source | CCFL [2 pcs] , W/O Driver |
| Weight | - |
| Designed For | Automotive Display |
| Interface Type | CMOS (1 ch, 6-bit) , 31 pins Connector |
| Environment | Operating Temperature: -40 ~ 85 °C - |
