| PartNumber | T260XW01 V5 |
| Brand | AUO |
| Size | 26.0 |
| Application | LCTV |
| Resolution | 1280(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | T260XW01 V5 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 26.0 inch |
| Display Mode | VA, Normally Black, Transmissive |
| Active Area | 566.4×339.84 mm |
| Outline | 620.8×389 mm |
| Surface | Hard coating, Antireflection |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 15/10 (Typ.)(Tr/Td); 12 (Typ.)(G to G) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 16 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Voltage | 5.0V (Typ.) |
