T320XVN02.A CELL

T320XVN02.A CELL
T320XVN02.A CELL
T320XVN02.A CELL
T320XVN02.A CELL thumb T320XVN02.A CELL thumb T320XVN02.A CELL thumb
Brand
AUO
Size
31.5
Application
LCTV
Resolution
1366×768
Composition
CELL
Brightness
0
CR
3000:1
Colors
16.7M
Backlight
No B/L
Interface
LVDS
In Stock
8728
Specifications
PartNumber T320XVN02.A CELL
BrandAUO
Size31.5
ApplicationLCTV
Resolution1366×768(RGB) , WXGA
CompositionCELL
Brightness0
CR3000:1
Colors16.7M
BacklightNo B/L
InterfaceLVDS
Panel BrandAUO
Panel ModelT320XVN02.A CELL
Panel Type a-Si TFT-LCD , CELL
Panel Size31.5 inch
Display ModeAMVA, Normally Black, Transmissive
Active Area697.685×392.256 mm
Outline713.68×408.72 mm
SurfaceAntiglare, Hard coating (3H)
Glass Depth0.50+0.50 mm
Transmissivity6.8% (Typ.)(with Polarizer)
Contrast Ratio3000:1 (Typ.)
Display Colors16.7M (8-bit)
Response Time6.5 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Voltage12.0V (Typ.)
Family Model
LK315T3LA61 SHARP 31.5 1366×768
LTA320HA02 Samsung 31.5 1920×1080
T320XVN01.0 AUO 31.5 1366×768
T320XVN01.0 CELL AUO 31.5 1366×768
T320XVN02.0 AUO 31.5 1366×768
T320XVN02.0 CELL AUO 31.5 1366×768
T320XVN02.9 CELL AUO 31.5 1366×768
T320XVN02.A CELL AUO 31.5 1366×768
T320XVN05.0 AUO 31.5 1366×768
V315H3-LE1 Innolux 31.5 1920×1080
