T370HW02 V4


Brand
AUO
Size
37
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
500
CR
2500:1
Colors
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
5
Specifications
PartNumber T370HW02 V4
BrandAUO
Size37
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness500 cd/m² (Typ.)
CR2500:1
Colors16.7M
BacklightCCFL
InterfaceLVDS
Panel BrandAUO
Panel ModelT370HW02 V4
Panel Type a-Si TFT-LCD , LCM
Panel Size37 inch
Display ModeAMVA, Normally Black, Transmissive
Active Area819.36×460.89 mm
Outline877×514.6 mm
SurfaceAntiglare (Haze 11%), Hard coating (3H)
Contrast Ratio2500:1 (Typ.)
Display Colors16.7M (8-bit), CIE193172%
Response Time6.5 (Typ.)(G to G)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeCCFLEmbedded (Inverter)
Signal InterfaceLVDS (2 ch, 8-bit), 51 pins
Input Voltage12.0V (Typ.)
Family Model
LC370EUN-SDV1 LG Display 37 1920×1080
T370HW02 V3 AUO 37 1920×1080
T370HW02 V4 AUO 37 1920×1080
T370HW02 V5 AUO 37 1920×1080
T370HW02 V9 AUO 37 1920×1080
T370HW02 VE AUO 37 1920×1080
T370HW03 VD AUO 37 1920×1080
T370HW03 VG AUO 37 1920×1080
T370HW03 VQ AUO 37 1920×1080
T370HW05 V8 AUO 37 1920×1080
