| PartNumber | T390XVN01.0 CELL |
| Brand | AUO |
| Size | 39 |
| Application | LCTV |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | T390XVN01.0 CELL |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 39 inch |
| Display Mode | AMVA, Normally Black, Transmissive |
| Active Area | 853.409×479.808 mm |
| Outline | 868.72×492.83 mm |
| Surface | Antiglare (Haze 2%), Hard coating (3H) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 8.0% (Typ.)(with Polarizer) |
| Contrast Ratio | 5000:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 6.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Voltage | 12.0V (Typ.) |
