| PartNumber | TCG070WVLPAANN-AN50-S |
| Brand | Kyocera |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800(RGB)×480, WVGA, 133PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 900 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | 2 |
| Interface | Parallel |
| Panel Brand | Kyocera |
| Panel Size | 7.0" |
| Display Area | 152.4(W)×91.44(H) mm |
| Outline Size | 165(W)×104.4(H) ×8.5(D) mm |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Best View on | 12 o'clock |
| Display Colors | 262K 49% NTSC |
| Frequency | - |
| Panel Weight | 195g (Typ.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Model | TCG070WVLPAANN-AN50-S |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 154.4(W)×93.4(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5/25 (Typ.)(Tr/Td) |
| Lamp Type | 2 strings WLED , 50K hours , Without Driver |
| Touch Screen | Without |
