| PartNumber | TL139GDXP01-00 |
| Brand | TIANMA |
| Size | 13.9 |
| Application | Laptop |
| Resolution | 3000(RGB)×2000, 259PPI |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | 420 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | TIANMA |
| Panel Model | TL139GDXP01-00 |
| Panel Size | 13.9" |
| Panel Type | LTPS TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 293.85(W)×195.9(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | SFT, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | WLED |
| Frequency | 60Hz |
| Touch Screen | - |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
