| PartNumber | TM022GDH17 |
| Brand | TIANMA |
| Size | 2.2 |
| Application | Mobile Phone |
| Resolution | 176(RGB)×220, QCIF+, 128PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | |
| Colors | 65K/262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 2.2" |
| Display Area | 34.848(W)×43.56(H) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | 65K/262K |
| Frequency | - |
| Weight | TBD |
| Panel Model | TM022GDH17 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | - |
| Lamp Type | WLED |
| Touch Screen | Without |
