| PartNumber | TM028HDZG59 |
| Brand | TIANMA |
| Size | 2.8 |
| Application | Mobile Phone |
| Resolution | 240×320 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 400:1 |
| Colors | 65K/262K |
| Backlight | WLED |
| Interface | 16-bit |
| Diagonal Size | 2.8 inch |
| Pixel Format | 240(RGB)×320 [QVGA] 141PPI |
| Active Area | 43.2(H)×57.6(V) mm |
| Luminance | 300 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 70/70/70/58 (Typ.)(CR≥10) |
| Support Color | 65K/262K 63% NTSC |
| Weight | TBD |
| Frame Rate | - |
| Interface Type | 16-bit 8080 parallel , 37 pins FPC |
| Power Supply | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Model | TM028HDZG59 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 50(H)×69.2(V) mm |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [1S4P] , W/O Driver |
| Designed For | Mobile Phone |
| Touch Panel | Without |
