| PartNumber | TM030LDHT13 |
| Brand | TIANMA |
| Size | 3.0 |
| Application | Handheld & PDA |
| Resolution | 240×400 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | |
| Colors | - |
| Backlight | WLED |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM030LDHT13 |
| Screen Size | 3.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 240(RGB)×400 (WQVGA) 156PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 38.88 × 64.8 (H×V) |
| Outline(mm) | - |
| Viewing Angle | - |
| Response | - |
| Good View at | - |
| Work Mode | ECB, Normally White, Transflective |
| Color Depth | |
| Mass | - |
| Used for | Handheld & PDA |
| Refresh Rate | - |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V0 | AUO | 3.0 | 320×240 |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| C-51505NFJ-SLW-APN | Kyocera | 3.0 | 20×2 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
