| PartNumber | TM035HDHP13 |
| Brand | TIANMA |
| Size | 3.5 |
| Application | Outdoor High Brightness Handheld & PDA |
| Resolution | 240(RGB)×320, QVGA, 114PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 3.5" |
| Display Area | 53.28(W)×71.04(H) mm |
| Outline Size | 64(W)×85(H) mm |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K 60% NTSC |
| Weight | - |
| Panel Model | TM035HDHP13 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | - |
| Lamp Type | WLED , 20K hours |
