| PartNumber | TM035HDZP04 |
| Brand | TIANMA |
| Size | 3.5 |
| Application | Automotive Display |
| Resolution | 240(RGB)×320, QVGA, 114PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 3.5" |
| Display Area | 53.28(W)×71.04(H) mm |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | TM035HDZP04 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 58.28(W)×74.04(H) mm |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | 30 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 10K hours , Without Driver |
| Touch Screen | - |
