| PartNumber | TM040YDH51 |
| Brand | TIANMA |
| Size | 4.0 |
| Application | Mobile Phone |
| Resolution | 480×800 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | 7S1P WLED , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM040YDH51 |
| Screen Size | 4.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 480(RGB)×800 (WVGA) 235PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 51.84 × 86.4 (H×V) |
| Outline(mm) | 57.24 × 98.3 × 2.3 (H×V×D) |
| Bezel Area(mm) | 52.84 × 87.4 (H×V) |
| Treatment | Clear |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) |
| Response | 20 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 60% NTSC |
| Mass | TBD |
| Used for | Mobile Phone |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
