| PartNumber | TM041XDHC02 |
| Brand | TIANMA |
| Size | 4.1 |
| Application | Industrial |
| Resolution | 720×720 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | 3S4P WLED , 30K hours , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Screen Size | 4.1 inch |
| Pixel Number | 720(RGB)×720 247PPI |
| Active Area(mm) | 73.98 × 73.98 (H×V) |
| Bezel Area(mm) | 74.78 × 74.78 (H×V) |
| Luminance | 300 (Typ.)(cd/m²) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 68% NTSC |
| Mass | 27.5g (Typ.) |
| Refresh Rate | - |
| Model Name | TM041XDHC02 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 77.98 × 82 (H×V×D) |
| Treatment | Hard coating |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Work Mode | SFT, Normally Black, Transmissive |
| Response | 35 (Typ.)(Tr+Td) ms |
| Used for | Industrial |
| Touchscreen | In-Cell Touch |
