| PartNumber | TM043NDHG21 |
| Brand | TIANMA |
| Size | 4.3 |
| Application | Handheld & PDA P |
| Resolution | 480×272 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | TM043NDHG21 |
| Diagonal Size | 4.3 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 128PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 95.04(H)×53.856(V) mm |
| Outline Dim. | 105.5(H)×67.2(V) ×3.2(D) mm |
| Bezel Area | 99.04(H)×54.86(V) mm |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 54% NTSC |
| Light Source | WLED [5S2P] , 50K hours , W/O Driver |
| Weight | TBD |
| Designed For | Handheld & PDA Portable Navigation |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| 43WQW3H | SII | 4.3 | 480×272 |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| AMS427GL34-1 | Samsung | 4.3 | 480×800 |
| DLC0430EZG-11 | Other | 4.3 | 480×272 |
| DLC0430NZG | Other | 4.3 | 480×272 |
| HSD043I9W1-A00-R0 | HannStar | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
