| PartNumber | TM047XDZP02 |
| Brand | Tianma |
| Size | 4.7 |
| Application | MPH |
| Resolution | 540(RGB)×960 , qHD |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | TIANMA |
| Panel Model | TM047XDZP02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 4.7 inch |
| Display Mode | SFT, Normally Black, Transmissive |
| Active Area | 58.32×103.68 mm |
| Outline | 62.72×113.53×1.78 mm |
| Surface | |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193170% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 5S2PWLEDWithout Driver |
| Signal Interface | MIPI (2 data lanes), 24 pins |
| Input Voltage | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
