| PartNumber | TM050RDH03-40 |
| Brand | TIANMA |
| Size | 5.0 |
| Application | Industrial Portable |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 5.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 188PPI |
| Active Area | 108(H)×64.8(V) mm |
| Bezel Area | 111.1(H)×67.9(V) mm |
| Luminance | 250 cd/m² (Typ.) |
| View Direction | 12 o'clock |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Support Color | 16.7M 50% NTSC |
| Weight | 57.0g (Typ.) |
| Frame Rate | 60Hz |
| Model | TM050RDH03-40 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 120.7(H)×75.8(V) ×3.1(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Response Time | 20 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [7S2P] , 20K hours , W/O Driver |
| Designed For | Industrial Portable Navigation MID UMPC MP3 PMP |
| Touch Panel | Without |
