| PartNumber | TM050RDH13 |
| Brand | TIANMA |
| Size | 5.0 |
| Application | Automotive Display |
| Resolution | 800(RGB)×480, WVGA, 188PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 5.0" |
| Display Area | 108(W)×64.8(H) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | 16.7M 50% NTSC |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | TM050RDH13 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 20 (Typ.)(Tr+Td) |
| Lamp Type | WLED |
| Touch Screen | Without |
