TM065QDHG03


Brand
Tianma
Size
6.5
Application
IA
Resolution
640×480
Composition
LCM
Brightness
CR
500:1
Colors
262K
Backlight
WLED
Interface
LVDS
In Stock
2492
Specifications
PartNumber TM065QDHG03
BrandTianma
Size6.5
ApplicationIA
Resolution640(RGB)×480 , VGA
CompositionLCM
Brightness
CR500:1
Colors262K
BacklightWLED
InterfaceLVDS
Panel BrandTIANMA
Panel ModelTM065QDHG03
Panel Type a-Si TFT-LCD , LCM
Panel Size6.5 inch
Display ModeTN, Normally White, Transmissive
Active Area132.48×99.36 mm
SurfaceAntireflection
Contrast Ratio500:1 (Typ.)
Display Colors262K (6-bit), CIE193150%
Response Time20 (Typ.)(Tr+Td)
Viewing Angle70/70/60/70 (Typ.)(CR≥10)(L/R/U/D)
Frequency60Hz
Lamp TypeWLED
Signal InterfaceLVDS (1 ch, 6-bit), 20 pins
Input Voltage3.3V (Typ.)
Family Model
AA065VB01 Mitsubishi 6.5 640×480
C065GW01 V0 AUO 6.5 400×234
C065GW04 V1 AUO 6.5 400×240
C065GW04 V2 AUO 6.5 400×240
DJ065NA-01C Innolux 6.5
L5F30818P04 SONY 6.5 800×480
LQ065T5DG05 SHARP 6.5 480×234
LQ065T9BR51U SHARP 6.5 400×240
LQ065T9DR51U SHARP 6.5 400×240
TM065QDHG03 Tianma 6.5 640×480
