| PartNumber | TM070DVHG01-41 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 1024(RGB)×600, WSVGA, 169PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 270 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 3S6P |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 7.0" |
| Display Area | 153.6(W)×90(H) mm |
| Outline Size | 171.5(W)×110.3(H) ×5.3(D) mm |
| Viewing Angle | 75/75/70/75 (Typ.)(CR≥10) |
| Best View on | 12 o'clock |
| Display Colors | 16.7M 50% NTSC |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | TM070DVHG01-41 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 20 (Typ.)(Tr+Td) |
| Lamp Type | 3S6P WLED , 20K hours , Without Driver |
| Touch Screen | PCAP |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| DLC0700EZG-2 | Other | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
