| PartNumber | TM070RDHG16 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Digital Photo Frame |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 7.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 134PPI |
| Active Area | 154.08(H)×85.92(V) mm |
| Bezel Area | - |
| Luminance | - |
| View Direction | 6 o'clock |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Support Color | 16.7M |
| Weight | - |
| Frame Rate | - |
| Model | TM070RDHG16 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Treatment | Antiglare |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | - |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED |
| Designed For | Digital Photo Frame Portable DVD Player |
| Touch Panel | Without |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
