| PartNumber | TM070RDHG34 |
| Brand | TIANMA |
| Size | 7.0 |
| Application | Industrial Outdoor H |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 3S8P WLED , 50K hours , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM070RDHG34 |
| Screen Size | 7.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 134PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 154.08 × 85.92 (H×V) |
| Outline(mm) | 164.9 × 100 × 6 (H×V×D) |
| Bezel Area(mm) | 157.08 × 89.39 (H×V) |
| Treatment | Antiglare |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Mass | TBD |
| Used for | Industrial Outdoor High Brightness Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
