| PartNumber | TM080RBHG30 |
| Brand | TIANMA |
| Size | 8.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | 3S12P WLED , 20K hours , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM080RBHG30 |
| Screen Size | 8.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 116PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 176.64 × 99.36 (H×V) |
| Outline(mm) | 192.8 × 116.9 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 375 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 262K/16.7M 65% NTSC |
| Mass | 280g (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
