| PartNumber | TM080VDSP03 |
| Brand | TIANMA |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 1200(RGB)×1920, WUXGA, 283PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 390 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 7S3P |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 8.0" |
| Display Area | 107.64(W)×172.224(H) mm |
| Outline Size | 114.58(W)×184.09(H) ×3.95(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 60% NTSC |
| Frequency | 60Hz |
| Panel Weight | TBD |
| Input Voltage | 3.3V (Typ.)(VCI) |
| Environment | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| Panel Model | TM080VDSP03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | 7S3P WLED |
| Touch Screen | Without |
