| PartNumber | TM089CFSP01 |
| Brand | TIANMA |
| Size | 8.9 |
| Application | 3D Printer |
| Resolution | 3840×2400, 508PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 800:1 |
| Colors | Monochrome |
| Backlight | No |
| Interface | |
| Panel Brand | TIANMA |
| Panel Size | 8.9" |
| Display Area | 192(W)×120(H) mm |
| Outline Size | 202(W)×133(H) ×1.24(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | - |
| Display Colors | Monochrome |
| Frequency | 60Hz |
| Weight | TBD |
| Panel Model | TM089CFSP01 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | Rectangle |
| Bezel Opening | - |
| Surface | Clear |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | SFT, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Transmissivity | 5.4% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
