| PartNumber | TM103XDHP95 |
| Brand | TIANMA |
| Size | 10.3 |
| Application | Outdoor High Brightn |
| Resolution | 1920×720 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 11S3P WLED , 10K hours , No Driver |
| Interface | |
| Manufacturer | TIANMA |
| Model Name | TM103XDHP95 |
| Screen Size | 10.3 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×720 200PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 243.648 × 91.368 (H×V) |
| Outline(mm) | 261 × 110.5 × 14.65 (H×V×D) |
| Bezel Area(mm) | 246.65 × 94.37 (H×V) |
| Treatment | Antiglare |
| Luminance | 950 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Response | 35 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | SFT, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Mass | TBD |
| Used for | Outdoor High Brightness Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
